| 英制規格 SIZE (in.) | 內徑 I.D. (mm) | 外徑 O.D. (mm) | 工作壓力 Max.W.P. | 爆破壓力 Min.B.P. | 彎曲半徑 Min.B.R. | |
| Min | Max | Max | (MPa) | (MPa) | (mm) | |
| 2-- 4 | 50.0 | 52.0 | 70.5 | 35 | 87.5 | 900 |
| 2 1/2-- 4 | 62.8 | 65.2 | 85.5 | 35 | 87.5 | 1100 |
| 3-- 4 | 74.6 | 77.4 | 109.0 | 35 | 87.5 | 1200 |
| 3 1/2-- 4 | 87.6 | 90.4 | 122.0 | 35 | 87.5 | 1300 |
| 4-- 4 | 100.5 | 103.5 | 130 | 35 | 87.5 | 1400 |
| 2--6 | 50.0 | 52.0 | 73.5 | 50 | 140 | 1000 |
| 2 1/2--6 | 62.8 | 65.2 | 92.0 | 50 | 140 | 1200 |
| 3--6 | 74.6 | 77.4 | 105.5 | 50 | 140 | 1300 |
| 3 1/2--6 | 87.6 | 90.4 | 121.5 | 50 | 140 | 1400 |
| 4--6 | 100.5 | 103.5 | 139.0 | 50 | 140 | 1600 |
加*項僅供參考，具體以管體為準
